Our signature values of high-performance, low-cost, accessible computing, distilled into an extraordinary microcontroller.
Dual Arm Cortex-M33 cores with hardware single-precision floating point and DSP instructions @ 150MHz.
Comprehensive security architecture, built around Arm TrustZone for Cortex-M.
Second-generation PIO subsystem provides flexible interfacing with no CPU overhead.
Switch it up
The unique dual-core, dual-architecture capability of RP2350 provides a pair of industry-standard Arm Cortex-M33 cores, and a pair of open-hardware Hazard3 RISC-V cores, selectable in software or by programming the on-chip OTP memory.
Raspberry Pi Pico 2
Our ready-made development board enables you to get hands-on with RP2350 right away.
Raspberry Pi Pico 2 comes with all the features of RP2350A, along with 4MB of on-board flash memory, packaged in a user-friendly form factor.
Build your custom board
RP2350 is now available at JLCPCB, a fast-turn PCB assembly service.
More options
RP2350A
30 GPIO
7×7 QFN 60 pin
RP2350B
48 GPIO
10×10 QFN 80 pin
RP2354A
30 GPIO
7×7 QFN 60 pin
Stacked 2MB flash
RP2354B
48 GPIO
10×10 QFN 80 pin
Stacked 2MB flash
Specification
Dual Arm Cortex-M33 or dual Hazard3 RISC-V processors @ 150MHz
520 KB on-chip SRAM
Robust and fully documented security features:
- ARM TrustZone for Cortex-M
- Optional boot signing, enforced by on-chip mask ROM, with key fingerprint in OTP
- Protected OTP storage for optional boot decryption key
- Global bus filtering based on Arm or RISC-V security/privilege levels
- Peripherals, GPIOs, and DMA channels individually assignable to security domains
- Hardware mitigations for fault injection attacks
- Hardware SHA-256 accelerator
2 × UART
2 × SPI controllers
2 × I2C controllers
24 × PWM channels
4/8 x ADC channels
1 × USB 1.1 controller and PHY, with host and device support
12 × PIO state machines
Software-compatible with RP2040
Open source C/C++ SDK, MicroPython support
Various packaging options:
- RP2350A: 30 GPIO, 7x7 QFN60
- RP2350B: 48 GPIO, 10x10 QFN80
- RP2354A: 30 GPIO, 7x7 QFN60, 2MB stacked flash
- RP2354B: 48 GPIO, 10x10 QFN80, 2MB stacked flash
Documents
Compliance
RP2350 has undergone extensive compliance testing and meets a number of regional and international standards.
View and download relevant certificates and conformity documents.
If you require any further information regarding compliance, please contact us at [email protected]
Obsolescence
RP2350
will remain in production until at least
January 2045
