mtg-crucible

A TypeScript library for rendering custom Magic: The Gathering card images. Runs in both Node and the browser from a single package — the right build is selected automatically via conditional exports.

Includes a react component for rendering resulting card images, complete with card rotations for double-faced cards, etc.

▶ Try it in your browser: the MTG Crucible Playground renders cards live — edit via a structured UI, the plaintext format, or raw JSON.

import { renderCard } from 'mtg-crucible';
import { writeFileSync } from 'fs';

const result = await renderCard(`
Crucible of Legends {3}
Legendary Artifact
Whenever a legendary creature you control dies, return it to your hand at the beginning of your next upkeep.
Flavor Text: Every great story begins with fire.
Rarity: Mythic Rare
Art URL: https://raw.githubusercontent.com/domainellipticlanguage/mtg-crucible/refs/heads/main/examples/crucible-art.png
`);

writeFileSync('crucible-of-legends.png', result.frontFace);

import { renderCard } from 'mtg-crucible';
import { writeFileSync } from 'fs';

const result = await renderCard({
  name: 'Crucible of Legends',
  manaCost: '{3}',
  typeLine: 'Legendary Artifact',
  abilities: 'Whenever a legendary creature you control dies, return it to your hand at the beginning of your next upkeep.',
  flavorText: 'Every great story begins with fire.',
  rarity: 'mythic',
  artUrl: 'https://raw.githubusercontent.com/domainellipticlanguage/mtg-crucible/refs/heads/main/examples/crucible-art.png',
});

writeFileSync('crucible-of-legends.png', result.frontFace);

• Standard (including colorless/Eldrazi full-bleed art)
• Planeswalker (3 and 4 ability variants)
• Saga
• Class
• Battle
• Adventure
• Transform (front and back)
• MDFC / Modal DFC (front and back)
• Split
• Fuse
• Flip (Kamigawa-style)
• Aftermath
• Mutate
• Prototype
• Leveler

Also supports Snow, Devoid, and Nyx borders, although currently only for Standard cards.

Parse and render a card. Accepts either a text-format string or a CardData object. Returns a RenderedCard with frontFace (raw image bytes as a Uint8Array), optional backFace (also a Uint8Array), format (the image type), orientation info, and rotation data for multi-face cards. The same call works in Node and the browser.

Options:

• quality — 'high' (2010x2814, default), 'medium' (745x1040), or 'low' (350x490)
• format — 'png' (default, lossless with transparency), 'jpeg' (smaller, no transparency, white corners), or 'webp' (smallest, with transparency)
• allowUnsafeArtUrls — defaults to false. See Security below.
• suppressAttribution — defaults to false. When true, omits the small "Powered by mtg-crucible" credit from the footer.

Convenience for the browser: wrap render bytes in a Blob with the right MIME type (e.g. for URL.createObjectURL or a fetch upload body). format defaults to 'png'; pass result.format to match the render.

Front-face image size for the Crucible of Legends card above (regenerate with npx tsx scripts/measure-sizes.ts):

JPEG and WebP both use lossy quality 60/70/80 for low/medium/high — a medium JPEG and a medium WebP are compressed alike, they just differ in how much quality each format buys at that setting. PNG is lossless and ignores it.

Parse a text-format card definition into a CardData object.

Convert a CardData object back to text format (round-trips with parseCard).

Normalize a CardData into NormalizedCardData with all fields resolved (frame colors derived, abilities parsed, defaults filled in).

Get the expected art image dimensions for a card. Returns primary dimensions, and secondary dimensions if the card has a linked card (e.g. transform, split, aftermath).

For convenience, cards can be defined in a plain text format, which is a superset of Scryfall's copy-pasteable text format.

Additional metadata fields can appear on any line (order doesn't matter):

• Rarity: Mythic Rare
• Flavor Text: Every great story begins with fire.
• Art URL: https://example.com/art.png
• Art Description: A fiery landscape
• Artist: Chris Rahn
• Set: MH3
• Language: EN
• Collector Number: 205
• Designer: Mark Rosewater
• Frame Color: Red and Blue
• Frame Effect: Nyx
• Accent Color: Green
• Name Line Color: Blue and Red
• Type Line Color: White
• PT Box Color: Black

These fields can be used to create flavorful card styles. For example:

Conduit of Fire and Ice {2}{U/R}
Artifact
Whenever you cast an instant or sorcery spell, choose one —
- Fire — Conduit of Fire and Ice deals 1 damage to each opponent.
- Ice — Scry 1.
Art URL: https://raw.githubusercontent.com/domainellipticlanguage/mtg-crucible/refs/heads/main/examples/conduit-art.png
Frame Effect: Nyx, Snow
Frame Color: Red, Blue
Accent Color: Red, Blue

The Candy Striper {2}{R}{W}
Legendary Creature — Nightmare Spirit
Haste, lifelink
Whenever the Candy Striper attacks, each opponent loses 1 life and you gain 1 life for each enchantment you control.
3/3
Art URL: https://raw.githubusercontent.com/domainellipticlanguage/mtg-crucible/refs/heads/main/examples/candy-striper-art.png
Frame Color: Red, White, Red, White, Red, White, Red, and White
Accent: Red, White, Red, White, Red, White, Red, and White
Name Line Color: Red, White, Red, White, Red, White, Red, and White
Type Line Color: Red, White, Red, White, Red, White, Red, and White
PT Box Color: Red, White, Red, White, Red, White, Red, and White

To define a composite card (split, modal double-faced, etc.) use the ---- separator between card parts.

Wine {1}{G}
Instant
Put a +1/+1 counter on each of up to two target creatures.
Art URL: https://raw.githubusercontent.com/domainellipticlanguage/mtg-crucible/refs/heads/main/examples/wine-art.png
Rarity: Uncommon
----
Dine {3}{B}
Instant
Destroy target creature. Create a Food token. (It's an artifact with "{2}, {T}, Sacrifice this token: You gain 3 life.")
Art URL: https://raw.githubusercontent.com/domainellipticlanguage/mtg-crucible/refs/heads/main/examples/dine-art.png

Crucible will infer the link type from the card parts, but if you want to be explicit, you can use the link type in the card definition:

Instead of ----, you can use one of --transform--, --mdfc--, --split--, --fuse--, --flip--, --adventure--, or --aftermath--.

Crucible provides a React component for rendering cards.

import { renderCard, toDisplayCard } from 'mtg-crucible';
import { MtgCard } from 'mtg-crucible/react';

const result = await renderCard(...);
const renderedCardDisplay = toDisplayCard(result);

<MtgCard
  card={renderedCardDisplay}
  cardText={renderedCardDisplay.scryfallText}   // invisible overlay, searchable with Ctrl+F
/>

The component supports:

• Rotations for non-standard cards (battles, flip, aftermath, etc.)
• Right-click context menu: download, copy image, copy text formats (hideMenuItems hides built-ins, extraMenuItems appends your own; the menu closes itself after any item runs, and copy items only appear when their text field is present in the display data)
• Invisible searchable text overlay for Ctrl+F

Hosts that drive display data from their own sources (instead of toDisplayCard) can build MtgCardDisplayData by hand — the text fields are optional — and use rotationShowsBackFace(rotation) (exported from every entry point) to know which face a pinned rotation state presents.

Styling hooks — set CSS custom properties on any ancestor instead of fighting the inline styles:

.my-small-cards { --mtg-card-radius: 6px; --mtg-card-face-shadow: none; }

Projects built with Crucible:

• This Magic Card Does Not Exist — A website for creating custom cards with AI.
• Playmat — a shared virtual table for paper-style Magic; every card face is MtgCard, custom tokens are crucible-rendered in each player's browser, and computeRotations drives flip/transform/battle orientation.
• Obsidian Custom MTG — an Obsidian plugin for creating custom cards in plaintext in your vault.
• Command Tower MCP — an MCP server for vibe-brewing Magic: The Gathering decks on Archidekt, with support for custom card creation.
• mtg-export — a CLI that turns a deck list into a printable PDF proxy sheet; its --modernize flag uses Crucible to redraw pre-M15 cards in modern frames with current oracle text.

Built something with Crucible? Open a PR to add it here.

Same package, same install — there's nothing browser-specific to add:

Bundlers (Vite, webpack, esbuild, Rollup, Parcel, Next.js, …) automatically pick the browser build via the package's "browser" export condition. If you'd rather not run a bundler at all, you can load it straight from an ESM CDN in a plain <script type="module">:

<script type="module">
  import { renderCard, toDisplayCard } from 'https://esm.sh/mtg-crucible';
  // …
</script>

import { renderCard, toDisplayCard } from 'mtg-crucible';

const result = await renderCard({...});

// To display a card, use toDisplayCard — a ready-to-render data URL (also works with <MtgCard>):
document.querySelector('img')!.src = toDisplayCard(result).frontFaceImageUrl;

result.frontFace is the raw bytes (Uint8Array). Reach for those when an API wants binary rather than a string — uploading (fetch(url, { body }), FormData), downloading (<a download>), or the clipboard. Wrap them in a Blob with toBlob:

import { toBlob } from 'mtg-crucible';

const blob = toBlob(result.frontFace, result.format);
await fetch('/upload', { method: 'POST', body: blob });

The browser build does not bundle the ~14 MB of frame assets. Frames, masks, symbols, and fonts are fetched on demand — only the ones a given card needs — and cached by the browser's HTTP cache. By default they come from a Cloudflare Pages CDN, versioned by asset major version (decoupled from the package version, so consumers across package versions share one warm cache):

https://mtg-crucible-assets-v<N>.pages.dev/

Assets are served with permissive CORS and a one-year immutable cache, so each file is fetched at most once and reused across renders, sessions, and every site on the CDN.

To self-host the assets (the assets/ folder is included in the npm package), override the base URL before your first renderCard:

import { setAssetBaseUrl } from 'mtg-crucible';

setAssetBaseUrl('https://your-cdn.example.com/mtg-crucible/assets/');

Notes:

• On the first render, the symbols a card uses are fetched on demand (a card-specific set, not the whole symbol manifest) and cached for subsequent renders.
• Fonts are loaded with FontFace and awaited before any text is drawn.
• Non-Chromium browsers may rasterize text slightly differently than the Node (@napi-rs/canvas) output; this is expected and acceptable.

Individual assets are also importable straight from the package (the ./assets/* subpath is exported), so a bundler can fingerprint and serve them like any local asset — no CDN, no hand-vendoring:

import wUrl from 'mtg-crucible/assets/symbols/mana/w.svg?url'; // vite

npm test          # run tests (vitest)
npm run build     # compile TypeScript
npm run dev       # start local dev server with hot reload

When rendering card data from untrusted users (e.g. on a public web server), leave allowUnsafeArtUrls off (the default). This blocks art URLs that point to:

• Local files (/path, ./path, file://)
• Loopback addresses (127.0.0.1, localhost)
• Private network ranges (10.0.0.0/8, 172.16.0.0/12, 192.168.0.0/16)
• Link-local addresses (169.254.0.0/16, including cloud metadata services like 169.254.169.254)

Safe to enable in single-user, CLI, or build-script contexts where the card data comes from you, not from untrusted users.

Public URLs like https://i.imgur.com/abc.png always work fine — only "local" or "internal" URLs are affected by allowUnsafeArtUrls. This prevents SSRF and local file disclosure attacks.

Note: protection is best-effort. There is a small DNS-rebinding race window between hostname resolution and connection. For stronger guarantees, enforce egress rules at the network level.

Card frame assets are derived from Card Conjurer, an open-source MTG card creation tool.

Magic: The Gathering is a trademark of Wizards of the Coast, LLC. This project is not affiliated with, endorsed by, or sponsored by Wizards of the Coast or Hasbro.
