GitHub - workofart/ml-by-hand: A deep learning library built from scratch with complex neural networks examples built on top for learning purposes.

from autograd.tensor import Tensor
from autograd.nn import Linear, Module
from autograd.optim import SGD
import numpy as np

class SimpleNN(Module):
    def __init__(self, input_dim, output_dim):
        super().__init__()
        # A single linear layer (input_dim -> output_dim).
        # Mathematically: fc(x) = xW^T + b
        # where W is weight and b is bias.
        self.fc = Linear(input_dim, output_dim)

    def forward(self, x):
        # Simply compute xW^T + b without any additional activation.
        return self.fc(x)

# Create a sample input tensor x with shape (1, 3).
# 'requires_grad=True' means we want to track gradients for x.
x = Tensor([[-1.0, 0.0, 2.0]], requires_grad=True)

# We want the output to get close to 1.0 over time.
y_true = 1.0

# Initialize the simple neural network.
# This layer has a weight matrix W of shape (3, 1) and a bias of shape (1,).
model = SimpleNN(input_dim=3, output_dim=1)

# Use SGD with a learning rate of 0.03
optimizer = SGD(model.parameters, lr=0.03)

for epoch in range(20):
    # Reset (zero out) all accumulated gradients before each update.
    optimizer.zero_grad()

    # --- Forward pass ---
    # prediction = xW^T + b
    y_pred = model(x)
    print(f"Epoch {epoch}: {y_pred}")

    # Define a simple mean squared error function
    loss = ((y_pred - y_true) ** 2).mean()

    # --- Backward pass ---
    # Ultimately we need to compute the gradient of the loss with respect to the weights
    # Specifically, if Loss = (pred - 1)^2, then:
    #   dL/d(pred) = 2 * (pred - 1)
    #   d(pred)/dW = d(xW^T + b) / dW = x^T
    # By chain rule, dL/dW = dL/d(pred) * d(pred)/dW = [2 * (pred - 1)] * x^T
    loss.backward()

    # --- Update weights ---
    optimizer.step()

# See the computed gradients for the linear layer’s weight matrix:
weights = model.fc.parameters["weight"].data
bias = model.fc.parameters["bias"].data
gradient = model.fc.parameters["weight"].grad
print("[After Training] Gradients for fc weights:", gradient)
print("[After Training] layer weights:", weights)
print("[After Training] layer bias:", bias)
assert np.isclose(x.data @ weights + bias, y_true)
