GitHub - turnstonelabs/turnstone

Experimental multi-node AI orchestration platform. Deploy tool-using AI agents across a cluster of servers, driven by message queues or interactive interfaces.

Beta — Use at your own risk. Turnstone is under active development and has not reached a stable release. APIs, configuration formats, and database schemas may change between versions without migration paths. We make no guarantees of determinism, reliability, or backward compatibility. Evaluate thoroughly before deploying to any environment where these properties matter.

Named after the Ruddy Turnstone (Arenaria interpres) — a shorebird that flips stones to discover what's hiding underneath.

What it does

Turnstone gives LLMs tools — shell, files, search, web, planning — and orchestrates multi-turn conversations where the model investigates, acts, and reports. It runs as:

• Interactive sessions — terminal CLI or browser UI with parallel workstreams
• Queue-driven agents — trigger workstreams via message queue, stream progress, approve or auto-approve tool use
• Multi-node clusters — generic work load-balances across nodes, directed work routes to a specific server
• Cluster dashboard — real-time view of all nodes and workstreams, reverse proxy for server UIs
• Intent validation — an LLM judge evaluates every tool call before approval, presenting risk assessments and evidence-based recommendations so users can make informed decisions instead of blindly approving raw tool calls
• Governance & compliance — RBAC, OIDC SSO (Okta, Azure AD, Google, Keycloak), tool policies, skills (reusable behavioral profiles with security scanning), usage tracking, and append-only audit logs
• Cluster simulator — test the stack at scale (up to 1000 nodes) without an LLM backend

Works with any OpenAI-compatible API (vLLM, llama.cpp, NVIDIA NIM) or Anthropic's native Messages API. Supports MCP for external tool servers with native deferred tool loading on Anthropic and OpenAI APIs (BM25 fallback for local models).

Quickstart

Interactive (terminal)

pip install turnstone
turnstone --base-url http://localhost:8000/v1

Interactive (browser)

turnstone-server --port 8080 --base-url http://localhost:8000/v1

Queue-driven (programmatic)

pip install turnstone[mq]
turnstone-bridge --server-url http://localhost:8080 --redis-host localhost

from turnstone.mq import TurnstoneClient

with TurnstoneClient() as client:
    # Generic — any available node picks it up
    result = client.send_and_wait("Analyze the error logs", auto_approve=True)
    print(result.content)

    # Directed — must run on a specific server
    result = client.send_and_wait(
        "Check disk I/O on this server",
        target_node="server-12",
        auto_approve=True,
    )

Cluster dashboard

pip install turnstone[console]
turnstone-console --redis-host localhost --port 8090

Then open http://localhost:8090 for the cluster-wide dashboard. Create workstreams from the console and interact with any node's server UI through the built-in reverse proxy — no direct server port access required.

Docker

cp .env.example .env  # edit LLM_BASE_URL, OPENAI_API_KEY, etc.
docker compose up     # starts redis + server + bridge + console (SQLite)

For production with PostgreSQL:

# Requires POSTGRES_PASSWORD and DB_BACKEND=postgresql in .env (or exported)
docker compose --profile production up  # adds PostgreSQL, uses it as database

Console dashboard at http://localhost:8090. See docs/docker.md for configuration, scaling, and profiles.

Simulator

Test the multi-node stack at scale without an LLM backend:

docker compose --profile sim up redis console sim

Or standalone:

pip install turnstone[sim]
turnstone-sim --nodes 100 --scenario steady --duration 60 --mps 10

See docs/simulator.md for scenarios, CLI reference, and metrics.

Architecture

Diagrams

Detailed UML diagrams are available in docs/diagrams/:

Governance

Turnstone includes a built-in governance layer for enterprise deployments — manage who can do what, which tools run unattended, and where every token goes.

• RBAC — 15 granular permissions, 3 built-in roles (admin / operator / viewer), custom roles, privilege escalation prevention
• OIDC SSO — single sign-on via any OpenID Connect provider (Okta, Azure AD, Google, Keycloak); Authorization Code Flow with PKCE, auto-provisioning, claim-based role mapping with demotion propagation; see docs/oidc.md
• Tool policies — glob-pattern rules (allow / deny / ask) with priority ordering; automate approvals or lock down dangerous tools
• Skills — reusable behavioral profiles with system prompts, {{variable}} substitution, session config (model, temperature, token budget), install-time security scanning, version history, external discovery (skills.sh / GitHub), and runtime skill tool for model-driven skill activation
• Usage tracking — per-request token and tool metrics, aggregation by day / model / user, automatic 90-day pruning
• Audit logging — append-only event trail for all admin mutations, IP-aware, 365-day retention

All governance features are managed through the console admin panel (13 tabs) and the full REST API. Runtime settings (model, tools, rate limiting, health, judge, memory) are configurable via the admin Settings tab — no config file edits or restarts needed for most changes. See docs/governance.md for setup and docs/settings.md for the settings reference.

Intent Validation (LLM Judge)

Every tool call that requires human approval is evaluated by an intent validation judge that provides a structured risk assessment alongside the approval prompt — so instead of "approve this bash command?", users see a verdict with risk level, confidence, recommendation, and reasoning.

The system uses a two-tier evaluation pipeline:

1. Heuristic tier (instant, free) — 36 pattern-based rules classify tool calls by severity. Catches destructive commands (rm -rf /, DROP TABLE), privilege escalation (sudo), credential access, supply chain risks, browser data export, cloud infrastructure mutations, and more. Results appear immediately.
2. LLM judge tier (async) — A full LLM evaluation runs in the background with access to read_file and list_directory for evidence gathering. The judge can inspect files that a write would overwrite, check directory contents before a delete, and cite specific evidence in its reasoning. Results update the UI progressively when ready.

The judge defaults to the same model as the session (self-consistency) but can be configured to use a separate model — useful when running a small local model for tasks but wanting a commercial model for safety evaluation.

[judge]
enabled = true           # on by default
model = ""               # empty = same as session model
provider = ""            # empty = same as session provider
timeout = 60.0           # generous for local models

Verdicts are persisted for audit and exposed via Prometheus metrics (turnstone_judge_verdicts_total, turnstone_judge_llm_latency_seconds).

Skills are also scanned at install time — the scanner evaluates content, supply chain, vulnerability, and declared capability risk across four independent axes. Results populate scan_status (tier) and scan_report (structured JSON breakdown) on the skill record so administrators can assess risk before enabling a skill.

Tool execution results are evaluated by an output guard before entering the conversation — detecting prompt injection payloads in fetched content, credential leakage in command output, and encoded payloads. Detected credentials are automatically redacted.

See docs/judge.md for the full guide.

Multi-node routing

Each Turnstone server runs a bridge process. Bridges share a Redis instance for coordination:

Routing rules:

1. Message has target_node → routes to that node's queue
2. Message has ws_id → looks up owner, routes to owning node
3. Neither → shared queue, next available bridge picks it up

Bridges BLPOP from their per-node queue (priority) then the shared queue. Directed work always takes precedence.

Tools

15 built-in tools, 2 agent tools, plus external tools via MCP:

When the total tool count exceeds a configurable threshold (default 20), MCP tools are automatically deferred using native defer_loading on Anthropic and OpenAI APIs, or a transparent client-side BM25 search for local models. The LLM discovers deferred tools on demand via a tool_search capability — no configuration needed beyond --tool-search auto (the default).

MCP Tool Servers

Turnstone supports the Model Context Protocol (MCP) for connecting external tool servers. MCP tools are discovered at startup, converted to OpenAI function-calling format, and merged with built-in tools. Each MCP tool is prefixed with mcp__{server}__{tool} to avoid name collisions. Tool lists stay fresh via push notifications (tools.listChanged), periodic polling for servers without push, and manual /mcp refresh.

Configure via config.toml or --mcp-config:

[mcp.servers.github]
command = "npx"
args = ["-y", "@modelcontextprotocol/server-github"]

[mcp.servers.github.env]
GITHUB_TOKEN = "ghp_..."

Or use a standard MCP JSON config file:

turnstone --mcp-config ~/.config/turnstone/mcp.json
turnstone-server --mcp-config ~/.config/turnstone/mcp.json

Use /mcp in the REPL to list connected tools, /mcp refresh to re-fetch tool lists from servers. MCP tools require user approval by default (overridden by --skip-permissions or UI auto-approve).

Multi-Model and Multi-Provider Support

Turnstone supports multiple model backends per server instance, including different LLM providers. ChatSession delegates all API communication to pluggable LLMProvider adapters — the internal message format stays OpenAI-like, and each provider translates at the API boundary. Define named models in config.toml and select per-workstream or switch mid-session with /model <alias>.

[models.local]
base_url = "http://localhost:8000/v1"
model = "qwen3-32b"
# provider defaults to "openai" (works with vLLM, llama.cpp, etc.)

[models.claude]
provider = "anthropic"
api_key = "sk-ant-..."
model = "claude-opus-4-6"
context_window = 200000

[models.openai]
base_url = "https://api.openai.com/v1"
api_key = "sk-..."
model = "gpt-5"
context_window = 400000

[model]
default = "local"              # which model to use by default
fallback = ["claude", "openai"]  # try these if the primary is unreachable
agent_model = "claude"         # optional: separate model for plan/task sub-agents

Supported providers: "openai" (default -- OpenAI, vLLM, llama.cpp, any OpenAI-compatible API) and "anthropic" (Anthropic Messages API, requires pip install turnstone[anthropic]).

Use /model to show available models, /model claude to switch. Workstreams created via the API accept an optional model parameter.

Configuration

All entry points read ~/.config/turnstone/config.toml. CLI flags override config values.

[api]
base_url = "http://localhost:8000/v1"
api_key = ""
tavily_key = ""        # only needed for local/vLLM models without native search

[model]
name = ""              # empty = auto-detect
temperature = 0.5
reasoning_effort = "medium"
default = "default"    # model alias for new workstreams
fallback = []          # ordered list of fallback model aliases
agent_model = ""       # model alias for plan/task sub-agents

[tools]
timeout = 30
skip_permissions = false
search = "auto"            # "auto" (enable when >threshold tools), "on", "off"
search_threshold = 20      # min tools before tool search activates
search_max_results = 5     # max tools returned per search query

[server]
host = "0.0.0.0"
port = 8080
max_workstreams = 50       # auto-evicts oldest idle when full

[redis]
host = "localhost"
port = 6379
password = ""

[bridge]
server_url = "http://localhost:8080"
node_id = ""           # empty = hostname_xxxx

[console]
host = "0.0.0.0"
port = 8090
url = "http://localhost:8090"  # used by CLI /cluster commands
poll_interval = 10

[health]
backend_probe_interval = 30
backend_probe_timeout = 5
circuit_breaker_threshold = 5
circuit_breaker_cooldown = 60

[ratelimit]
enabled = true
requests_per_second = 10.0
burst = 20

[database]
backend = "sqlite"     # "sqlite" (default) or "postgresql"
path = ".turnstone.db" # SQLite file path (relative to working directory)
# url = "postgresql+psycopg://user:pass@host:5432/turnstone"  # PostgreSQL
# pool_size = 2        # PostgreSQL connection pool size (per process)

[judge]
enabled = true         # intent validation for tool approvals (--no-judge to disable)
model = ""             # empty = same as session model (self-consistency)
provider = ""          # empty = same as session provider
timeout = 60.0         # LLM judge timeout in seconds
confidence_threshold = 0.7

[mcp]
config_path = ""       # path to MCP JSON config file (alternative to TOML sections)
refresh_interval = 14400  # periodic refresh for servers without push notifications (seconds, 0 to disable)

[mcp.servers.example]  # one section per MCP server
command = "npx"
args = ["-y", "@modelcontextprotocol/server-example"]
# type = "stdio"       # "stdio" (default) or "http"
# url = ""             # for HTTP transport

Precedence: CLI args > environment variables > config.toml > defaults.

Workstreams

Parallel independent conversations, each with its own session and state:

Idle workstreams are automatically cleaned up after 2 hours (configurable). In multi-node deployments, workstream ownership is tracked in Redis — follow-up messages auto-route to the owning node.

Monitoring

/metrics endpoint exposes Prometheus-format metrics:

• turnstone_tokens_total{direction} — prompt/completion token counters
• turnstone_tool_calls_total{tool} — per-tool invocation counts
• turnstone_workstream_context_ratio{ws_id} — per-workstream context utilization
• turnstone_http_request_duration_seconds — request latency histogram
• turnstone_workstreams_by_state{state} — workstream state gauges
• turnstone_sse_connections_active — current open SSE connections
• turnstone_ratelimit_rejected_total — requests rejected by rate limiter
• turnstone_backend_up — LLM backend reachability (0/1)
• turnstone_circuit_state — circuit breaker state (0=closed, 1=open, 2=half_open)
• turnstone_workstreams_evicted_total — workstreams auto-evicted at capacity
• turnstone_judge_verdicts_total{tier,risk_level} — intent validation verdicts by tier and risk
• turnstone_judge_llm_latency_seconds — LLM judge evaluation latency histogram
• turnstone_judge_enabled — whether the intent validation judge is active (0/1)

Per-workstream metrics are labeled by ws_id (bounded by [server].max_workstreams).

Health & Rate Limiting

Health degradation. A background BackendHealthMonitor probes the LLM backend every backend_probe_interval seconds. When the backend is unreachable, /health reports "status": "degraded" (HTTP 200) and the turnstone_backend_up gauge drops to 0.

Circuit breaker. After circuit_breaker_threshold consecutive probe failures the circuit opens (CLOSED -> OPEN). While open, ChatSession._create_stream_with_retry skips the backend entirely and returns an error. After circuit_breaker_cooldown seconds the circuit enters HALF_OPEN, allowing a single probe. A successful probe closes the circuit; a failure re-opens it.

Per-IP rate limiting. When [ratelimit].enabled is true, each client IP is tracked with a token-bucket limiter (requests_per_second / burst). Rate limiting is applied in do_GET/do_POST after authentication but before route dispatch. /health and /metrics are exempt. Requests that exceed the limit receive HTTP 429 with a Retry-After header.

Workstream eviction. When WorkstreamManager.create() would exceed max_workstreams, the oldest IDLE workstream is automatically evicted and the turnstone_workstreams_evicted_total counter is incremented. Configure via [server].max_workstreams (default 50).

Requirements

• Python 3.11+
• An OpenAI-compatible API endpoint (vLLM, NVIDIA NIM, llama.cpp, etc.) or an Anthropic API key
• Redis (for message queue bridge — pip install turnstone[mq])
• Anthropic provider (optional — pip install turnstone[anthropic])
• PostgreSQL (optional, for production — pip install turnstone[postgres])
• Git LFS (for cloning — diagram PNGs are stored in LFS)

License

Business Source License 1.1 — free for all use except hosting as a managed service. Converts to Apache 2.0 on 2030-03-01.
