GitHub - dronnix/bwarr: Black-White Array: fast, ordered data structure based on arrays with O(log N) memory allocations

What is it?

The Black-White Array (aka BWArr) is a fast, ordered data structure based on arrays with $O(\log N)$ memory allocations.

The idea of Black-White Array was invented and published by professor Z. George Mou in Black-White Array: A New Data Structure for Dynamic Data Sets. This repository contains the first public implementation.

Key features:

• $O(\log N)$ memory allocations for Inserts - no pressure on GC;
• Fast insert, delete, and search operations $O(\log N)$ time amortized complexity;
• Array-based and pointerless makes it CPU-friendly: cache locality / sequential iteration / etc;
• Supports duplicate elements natively (multiset behavior) - no need for wrapping values into structs to make them unique;
• Drop-in replacement for github.com/google/btree and github.com/petar/GoLLRB;
• Low memory overhead - no pointers per element, compact memory representation;
• Easily serializable;

Tradeoffs

• One per $N$ insert operations complexity falls down to $O(N)$, though amortized remains $O(\log N)$. For real-time systems, it may introduce latency spikes for collections with millions of elements. Could be mitigated by async/background inserts.
• For a small number of elements Search()/Delete() operations may take $O((\log N)^2)$. 50% of elements take $O(\log N)$ time, 75% - $O(2\log N)$, 87.5% - $O(3\log N)$, etc.
• When deleting long series of elements, a Max()/Min() operation can take $O(N/4)$. Amortized complexity for series of calls remains $O(\log N)$.
• When deleting long series of elements, iteration step can take $O(N/4)$. Amortized complexity for iteration over the whole collection remains $O(\log N)$ per element.

Use-case

In-memory collections with read-write ratio 1:1 < r:w < 10:1. BWArr is optimized for heavy insertions and deletions (with low allocations and fragmentation), while still providing fast search and iteration.

Benchmarks

Benchmarks in comparison with Google BTree.

Insert

Measures the time, allocs and allocated KBs to insert N unique random int64 values into an empty data structure. Both BWArr and BTree start empty and insert all values one by one.

Allocations on smaller values:

Get

Measures the time to look up N values by their keys in a pre-populated data structure. The data structure is populated with all values before timing starts, then each value is retrieved by key.

Iterate

Measures the time to iterate through all N values in sorted and non-sorted orders.

More benchmarks

Additional benchmarks and details are available in the bwarr-bench repository. More methods will be added, also expect separate benchmarks for AMD64 and ARM64 architectures.

Installation

Requires Go 1.22 or higher.

go get github.com/dronnix/bwarr

Then import in your code:

import "github.com/dronnix/bwarr"

Usage

Basic Example

package main

import (
    "cmp"
    "fmt"

    "github.com/dronnix/bwarr"
)

func main() {
    // Create a BWArr with an integer comparison function
    // The second parameter (10) is the initial capacity hint
    bwa := bwarr.New(func(a, b int64) int {
        return cmp.Compare(a, b)
    }, 10)

    // Insert elements
    bwa.Insert(42)
    bwa.Insert(17)
    bwa.Insert(99)
    bwa.Insert(23)
    bwa.Insert(8)

    fmt.Printf("Length: %d\n", bwa.Len()) // Output: Length: 5

    // Get an element
    val, found := bwa.Get(42)
    if found {
        fmt.Printf("Found: %d\n", val) // Output: Found: 42
    }

    // Delete an element
    deleted, found := bwa.Delete(17)
    if found {
        fmt.Printf("Deleted: %d\n", deleted) // Output: Deleted: 17
    }

    // Iterate in ascending order
    fmt.Println("Elements in sorted order:")
    bwa.Ascend(func(item int64) bool {
        fmt.Printf("  %d\n", item)
        return true // return false to stop iteration early
    })
    // Output:
    //   8
    //   23
    //   42
    //   99
}
