What is Misterio?

Docker-compose based Ansible/SaltStack/NameYour minimalistic alternative. Mysterio Marvel It is super-easy to use.

Cool! The new Python version is easier to use and understand.

Misterio is a Python command you can use to "apply" a set of roles to an infinite number of hosts. Less than 200 lines of Python code HELP INCLUDED (sorry Ansible :)

Misterio is able to manage a set of compose target as one, applying status changes easily.

From Misterio 0.1.6 I started to write unit tests using DeepSeek-AI + Claude Opus: I explicit disclosure it.

Simple usage example

Suppose you have two hosts called alice and bob. You want to run elasticsearch on both of them, and one gitlab instance on bob. So you define:

misterio_project/              # Misterio home directory
├── hosts/
|   |
|   ├── misterio.toml          # optional extended configuration (see below)
│   ├── alice/
│   │   └── elasticsearch.env  # empty file
│   └── bob/
│       └── gitlab.env         # empty file
|           elasticsearch.env  # empty file

└── roles/
|   ├── elasticsearch/
|   │   └── docker-compose.yml
|   └── gitlab/
|       └── docker-compose.yml
|
└── attic/    # This is a special folder used by support utilities: it is automatically created

Then running something like

misterio --home ./misterio_project rebuild

will build the services and run them. To see the logs you can use

misterio --home ./misterio_project -- logs --tail 10

For simple stats on a single host:

misterio -h xwing -- stats --no-stream

You can further customize the roles, adding variables inside the elasticsearch.env file (like Elastic Search cluster details)

Why?

  1. The only dependency is a recent version of docker CE (on target hosts) and python 3 (on misterio host).
  2. It does not rely on docker swarm or on K8s. It can run even on ultra-small nano containers on Amazon (1GB RAM), provided you have a little swap (tested)
  3. It is agent-less. It depends only on docker daemon on the target. Docker communication is done via ssh and can be further configured via the .ssh/config file (for instance to setup keys, tunneling, etc)
  4. Everything must be versioned to work: you cannot easily "forget" something on your local machine. It respects the Infrastructure as Code paradigm.

Details on env file

For every hostname, define a directory inside hosts/ Put in it an env file based on this syntax:

where @inst is OPTIONAL and can be used to have multiple instances of a role on the same machine. Misterio will configure them one by one (see below misterio-add)

The magic

For every role on the target machine misterio will:

  1. for each role, copy the correct env file calling it .env
  2. pass the command you provide to docker-compose
  3. fail fast or loop

The "@rebuild" pseudo-command will do a down + build and up in one step. The "@refresh" will also pull data.

Distributed

Because misterio manages the DOCKER_HOST automatically, it is already distributed.

About extended configuration

Working with OrbStack I faced some troubles because of how OrbStack configures the docker client, so I introduced "extended configuration": see sample file

OrbStack uses docker "context" which is a smart way to define a lot of access configurations in docker. The trouble is OrbStack defines a new default which does not play nice with my setup.

Docker contexts are more flexible than hostnames, but hostnames are very easy to understand, and we want to try to be forward compatible.

Parsing of extended configuration is available from version 0.1.6 onwards and it is totally optional. You also require Python 3.11+

Python official version

Look at https://pypi.org/project/misterio/ for the latest version

Python development version

Install on your virtualenv with

    python3 -m venv .venv
    . .venv/bin/activate
    pip install -e .

    misterio --help

Testing

    . .venv/bin/activate
    pip install -e ".[test]"
    python -m pytest

Support commands

misterio-add

misterio-add adds a role to a host, checking if it does not exist.

It leverages the COMPOSE_PROJECT_NAME variable to define different compose instances.

misterio-mv

misterio-mv command can be used to migrate a stateless service from one host to another. It removes (compose down) the source service, moves the env file and then reboots (up -d) the other one.

misterio-rm

misterio-rm command deletes a role from a host, ensuring it is destroyed and no dangling instances are kept. Because env files are valuable (they can contain secrets and important configs) the command moves them to a special "attic" directory, which you can recover from.

!! The support commands are not required to run misterio. They are provided to leverage DevOps pipelines with a consistent way of manipulating the misterio ecosystem.

About special localhost hostname

Localhost hostname support was dropped in favor of misterio.toml extended configuration.

The Bonus: stacks

Misterio is also a collection of ready-made docker-compose infrastructure you can jump into. For instance, jenkins-with-docker show you how to get a dockerized-jenkins with:

  • self running git server
  • access to docker daemon to self-build stuff using docker plugin

Tips

You can use the pseudo command --list to get the list of all the roles, and the --single-role option to restrict only to a role.

Under docker for Windows, add COMPOSE_CONVERT_WINDOWS_PATHS=1 to your env path if you plan to bind stuff like

/var/run/docker.sock:/var/run/docker.sock

This will enable your roles to run on Windows and on Linux daemons seamlessly. See https://stackoverflow.com/a/52866439/75540 for more details

The Hype

  1. You can add git submodules below roles/ to link recipes (your personal "Ansible Galaxy" is... Docker Hub!)
  2. No complex stuff to learn: it is just DOCKER!

Podman

Podman is not tested, and it could require a modification to the way the DOCKER_HOST variable is addressed too. Anyway, if you are able to create a pull request with a --podman option, I will be happy to merge it.

Other alternative

https://github.com/piku/piku is a Heroku-like alternative, based on Python and not requiring Docker.

Legacy

The old misterio bash version can be found under ./old_sh_version folder: it is a 4-year-old version, which can still be used if you want to further reduce dependencies on the misterio controlling host.
